室内LED显示屏

1、产品使用国外进口胶水封装，具备极佳的气密性；灯珠内部采用铜支架，优越的延展性、散热性、防潮性，极大的提高灯珠寿命。面发光技术，磨砂雾面，外观清新悦目，灯珠内封装红色、绿色、蓝色芯片各一个，通过表面贴装技术（SMT）焊接在 PCB 板上。

2、产品使用全新低功耗 PWM-SS 双节能恒流驱动 IC，采用动态节能技术加低压供电设计组成高效节能解决方案。通过计算机控制，显示视角宽阔，色彩纯正一致协调，亮度稳定均匀，文字、图像、视频清晰。

3、产品外型精致美观，坚固耐用。底壳有用于安装模组的 M4 螺纹孔。可将磁吸磁柱安装在模组上，再装成整屏,或使用螺钉将模组固定在箱体上，再将箱体拼接成整屏。

 本公司产品不限于以下型号，欢迎来电咨询

     技术参数                                                                                            1，像素间距（mm）                  2

     2，像素密度（dot/m²）            250000

     3，模组分辨率                           160x80

     4，模组尺寸（mm）                  320x160

     5，模组最平均功率（w）           10w@vcc=5v

     6，使用寿命（小时）                 ≥100000

     7，控制方式                              计算机同步，视频同步，实时显示

      技术参数

      1，像素间距（mm）                  2.5

      2，像素密度（dot/m²）            160000

      3，模组分辨率                           128x64

      4，模组尺寸（mm）                  320x160

      5，模组最平均功率（w）           9w@vcc=5v

      6，使用寿命（小时）                 ≥100000

                                                                                                                                           7，控制方式                              计算机同步，视频同步，实时显示

                                                         技术参数

                                                         1，像素间距（mm）                  3

                                                         2，像素密度（dot/m²）            111111

                                                         3，模组分辨率                           64x64

                                                         4，模组尺寸（mm）                  192x192

                                                         5，模组最平均功率（w）           10w@vcc=5v

                                                         6，使用寿命（小时）                 ≥100000

                                                         7，控制方式                              计算机同步，视频同步，实时显示

                                                                   技术参数

                                                                   1，像素间距（mm）                 4.75

                                                                   2，像素密度（dot/m²）            44321

                                                                   3，模组分辨率                           64x32

                                                                   4，模组尺寸（mm）                 303.7±0.11x151.8±0.20

                                                                   5，模组最大功率（w）              12.6w@vcc=5v

                                                                   6，使用寿命（小时）                 ≥50000
